SV 977D User Manual - Appendixes
Word
number
Name
Comment
3 – HP10
4 – Vel1
5 – Vel3
6 – Vel10
7 – VelMF
8 – Dil1
9 – Dil3
10 – Dil10
21 – Wh
measurement filter in sound measurement mode:
0 – HP
1 – Z
2 – A
3 – C
5 – B
6 – LF
7 – U
8 – AU
3
LoggerRes
bit mask of results written to logger in vibration measurement mode:
1 – Peak
2 – P–P
4 – Max
8 – RMS
bit mask of results written to logger in sound measurement mode:
1 – Peak
2 – Max
4 – Min
8 – Leq
16 – LR1
32 – LR2
64 – LXY
…
reserved
Table B.15. Reserved block
Word
number
Name
Comment
0
0nn21h
21h = block identifier
0nnh = block length in words
…
reserved
Table B.16. Marker parameters
Word
number
Name
Comment
0
0043h
43h = block identifier
1
BlockLength
block length in words
