SV 977D User Manual - Appendixes
Word
number
Name
Comment
2
MarkerCount
number of markers
3..7
MarkerName[1]
name of the first marker (10 ASCII symbols)
8
reserved
9
MarkerType[1]
type of the first marker:
0 – block marker
1 – point marker
...
parameters of further markers
…
reserved
Table B.17. Statistical analysis parameters (relevant only in Sound measurement mode)
Word
number
Name
Comment
0
0nn09h
09h = block identifier
0nnh = block length in words
1
00pxxh
p = number of profiles, 0xxh = profile bit mask (bit mask informs for
which profiles parameters are available)
2..
ProfileStat[1]
Internal block with identifier 0Ah containing parameters of the first
profile (if the first profile bit mask is set)
...
...
...
...
ProfileStat[p]
internal block with 0Ah containing parameters of the last profile (if the
last profile bit mask is set)
…
reserved
Table B.18. Parameters of the profile histogram (block exists only inside the main block – see
Table B.17)
Word
number
Name
Comment
0
0nn0Ah
0Ah = block identifier
0nnh = block length in words
1
N
number of statistical class histogram
2
BottomClass
first class histogram in 0.01 dB format
3
ClassWidth
class histogram width in 0.01 dB format
…
reserved
Table B.19. Octave and partial octave spectra analysis
Word
number
Name
Comment
0
004Ah
4Ah = block identifier
1
BlockLength
block length in words
2
reserved
3
SystemBase
filter database (2 or 10)
