Svantek SV 977D User Manual

234
SV 977D User Manual - Appendixes
Word
number
Name
Comment
4
MStFirmwareVersion
firmware version number of the monitoring stations; for example, 123
means version 1.23
5..6
MStIntTimeSec
meteorological results averaging time used in the monitoring station
7
Temperature
temperature measurement result in format 0,1°C
8
Pressure
atmospheric pressure measurement result in hectopascals
9
Humidity
relative humidity measurement result in format 0,1%
10
AvgWindSpeed
average wind speed measurement result in the format 0,1 m/s
11
WindDirection
wind direction in degrees for maximum wind speed (if the parameter
value is equal to 0FFFFh the direction is undefined)
12
MaxWindSpeed
maximum wind speed measurement result in the format 0,1 m/s
13..14
WindDirTotalPuffs
number of wind measurement samples
15
N
number of directions of wind direction distribution
16..
WindDir[N]
wind direction distribution table - values in the format 0.1%
16+N
M
number of directions of measurement of maximum wind speed
...
WindMax[M]
table of maximum wind speeds - values in 0.1 m / s format
16+N+M
V
number of directions for measuring average wind speeds
...
WindAver[V]
table of average wind speeds - values in the format 0,1 m/s
16+N+M+
V
RainDetection
flag of precipitation:
Note: if the flag is zero, the next 10 words of precipitation parameters
are not present in this block
+[0]
[RainIntensity]
rainfall intensity in 0.1 mm / h format (this is a rolling average for 1
minute measurement)
+[1..2]
[RainAccumulation]
sum of rainfall in 0.01 mm format
+[3..4]
[RainDuration]
duration of precipitation in seconds
+[5]
[HailIntensity]
hail intensity in the format 0,1/cm
2
h (this is a rolling average for 1
minute measurement)
+[6..7]
[HailAccumulation]
sum of hail in the format 0,1/cm
2
+[8..9]
[HailDuration]
duration of the hail in seconds
…
reserved
Table B.52. STIPA results
Word
number
Name
Comment
0
0061h
61h = block identifier
1
BlockLength
block length in words
2
STI
STI result in the format 0.01dB
3
LAeq
LAeq result in the format 0.01dB
4
LCeq
LCeq result in the format 0.01dB
5
N
number of frequencies of the STIPA analysis
6
LZeq[1]
LZeq result number for the first frequency in the format 0.01dB
7
Err1[1]
m(f1) error flag for the first frequency (0,1)
8
Mf1[1]
m(f1) result value for the first frequency in the format 0.01
9
Err2[1]
m(f2) error flag for the first frequency (0,1)
10
Mf2[1]
m(f2) result value for the first frequency in the format 0.01
i*5+1
LZeq[i]
LZeq result number for the next frequency in the format 0.01 dB
i*5+2
Err1[i]
m(f1) error flag for the next frequency (0,1)
