SV 977D User Manual - Appendixes
Table B.50. Results of GPS measurements
Word
number
Name
Comment
0
0nnxxh
0xxh = block identifier:
34h – GPS measurement results at the beginning of the
measurement cycle
35h – GPS measurement results at the end of the measurement
cycle
0nnh = block length in words
1
Quality
GPS signal quality:
0 – no signal
1 – „FIX”
2 – „FIX–DIF”
2
TimeSec
value of seconds of real-time clock
3
TimeMin
value of minutes of real-time clock
4
TimeHour
value of hours of real-time clock
5
DateDay
day number
6
DateMonth
month number
7
DateYear
year number
8
LatitudeDeg
latitude - number of degrees
9
LatitudeMin
latitude - number of minutes
10
LatitudeSec
latitude - number of seconds
11
LatitudeMSec
latitude - number of milliseconds in the format 10 ms
12
LatitudeDir
latitude - orientation (ASCII symbol):
N – latitude north
S – latitude south
13
LongitudeDeg
longitude - number of degrees
14
LongitudeMin
longitude - number of minutes
15
LongitudeSec
longitude - number of seconds
16
LongitudeMSec
longitude - number of milliseconds in the format 10 ms
17
LongitudeDir
longitude - orientation (ASCII symbol):
E – longitude east
W – longitude west
18
Altitude
altitude - the number of meters
19
Altitude10
absolute altitude - number of decimetres
20
Speed
speed in format 0,01 km/h
…
reserved
Table B.51. Meteorological measurement results (Meteo)
Word
number
Name
Comment
0
002Ah
2Ah = block identifier
1
BlockLength
block length in words
2
MStUnitNumber
serial number of the monitoring station
3
MStUnitType
type of monitoring station:
210 – SV 210 monitoring station
211 – SV 211 monitoring station
