Svantek SV 977D User Manual

232
SV 977D User Manual - Appendixes
Word
number
Name
Comment
5
Result[1]
value of the first result in the format 0,01 dB
6
Result[2]
value of the second result in the format 0,01 dB
...
...
...
...
Result[N+T–1]
value of the penultimate result in the format 0,01 dB
...
Result[N+T]
value of the last result in the format 0,01 (number of spectral lines
and the number of aggregate results are determined in the
corresponding FFT analysis block of results - see
Table B.21)
…
reserved
Table B.48. Results of statistical analysis
Word
number
Name
Comment
0
0xx0Bh
0Bh = block identifier
0xxh = profile bit mask
1
BlockLength
block length in words
2..3
Histogram[1]
histogram counter of the first class
4..5
Histogram[2]
histogram counter of the second class
...
...
...
...
Histogram[N–1]
histogram counter of the penultimate class
...
Histogram[N]
histogram counter of the last class (number of statistical classes of
the histogram N is given in the block of profile histogram parameters
- see
Table B.18)
…
reserved
Table B.49. Results of statistical analysis for 1/1 and 1/3 octaves
Word
number
Name
Comment
0
0xx14h
14h = block identifier
0xxh = spectrum band number (counted from 1) for which the
histogram is calculated
1
BlockLength
block length in words
2..3
Histogram[1]
histogram counter for the first class
4..5
Histogram[2]
histogram counter for the second class
...
...
...
...
Histogram[N–1]
histogram counter for the penultimate class
...
Histogram[N]
histogram counter for the last class (number of statistical classes of
the histogram N is given in the block of 1/1 and 1/3 octave histogram
parameters – see
Table B.20)
…
reserved
