097-55501-01 Issue 6 – June 2003 137
2
5
3
Operational Verification & Configuration
Set date and time
3 Setting of date and time ensures that reported and logged events will correctly indicate
time of occurrence.
If using TimeScan THC:
a. As a security measure, a logon to the THC software is needed to allow attempting of
configuration actions. This only needs to be done once each time the software is started.
Select the Mode of Operation -> Advanced Mode... menu, which displays the
following screen:
In the User Name field, select admin from the pull-down list. The default password is
also admin, so type admin into the Password field. Then select Login. A screen appears
indicating that THC is now in advanced mode, which means that configuration is now
allowed.
Note: It is possible to change users and passwords on this feature via the Mode of
Operation -> Advanced Mode... menu, but that is beyond the scope of this procedure. It
is assumed in this step that the default settings still apply.
b. Set the date and time by selecting the Service -> Set TimeHub Date and Time menu,
which displays this screen:
The software uses the PC time as a suggestion, but the entry can be changed as
desired. This example shows that the date is set to 2002, October 11 and the time is set
to 11:58:51.
c. Select OK to actually set the date and time.
Procedure 4-9. System Configuration (Cont’d)
Step Action
