Syspine A50 - Hardware Installation Procedures

Installation
16 Hardware Installation
2.1 Hardware Installation
2.1.1 Typical LAN Setup
The diagram describes typical LAN architecture without the Security Gateway
using the Syspine Phone System.
N
OTE: The standard unit does not contain the Security Gateway (WAN).
PSTN INTERNET
Typical LAN Set Up
LAN Switch
Router
Response Point Administrator
DOS-A50
IP Phone
IP Phone
