Syspine A50 - Connecting the DOS-A50 to the LAN

Installation
22 Hardware Installation
2.1.5 Connecting the DOS-A50 to the LAN
After locating the DOS-A50, connect to the LAN by performing the following
steps:
1. Insert the cable pin into the left-hand side of the DOS-A50 case as shown.
2. Connect the AC adapter to the DOS-A50 and secure it in place as shown.
P4 P3 P2 P1
P8 P7 P6 P5
DC IN
P4 P3 P2 P1
P8 P7 P6 P5
DC IN
