6 Using the product
149
Designation Explanation
Selection list for
the unit (if manual
division is activated)
Unit of the time axis:
• sec (second)
• min (minute)
• h (hour)
• d (day).
Pos: 167 /TD/Produ kt verwenden/testo Sa veris/05 a-3 Histogra mm/00 Histogramm @ 1\mod_1 198143235359_79.d ocx @ 6804 @ 3 @ 1
6.6.2. Histogram view
In this view, the readings are shown as a histogram, meaning the
last reading of a channel is shown as a column.
In the Start | View menu, the Histogram command is activated.
Now you have to select the data record that you wish to display.
1. Select the day or time period in the calendar that should be
evaluated.
2. In the tree structure of the data range, open the group that
contains the data to be displayed.
- The histogram for the selected data is shown.
> If necessary, deactivate channels via the checkboxes for the
display.
Pos: 168 /TD/Produ kt verwenden/testo Sa veris/05 a-4 Zahlenfe ld/00 Zahlenfeld @ 1\mod_1 198143746015_79.d ocx @ 6815 @ 4 @ 1
6.6.3. Monitor view
In this view, the readings are shown as number fields. If you take
advantage of the opportunity to insert a background picture, e.g.
the floor plan of a building, you quickly achieve a spatial overview
of the current climatic conditions.
In the Start | View menu, the Monitor command is activated. Now
you have to select the data record that you wish to display.
1. Select the day or time period in the calendar that should be
evaluated.
2. In the tree structure of the data range, open the zone that
contains the data to be displayed.
- The monitor display for the selected data is shown.
> If necessary, deactivate channels via the checkboxes for the
display.
Pos: 169 /TD/Produ kt verwenden/testo Sa veris/05b Tabellen ana lysieren/00 Tabel len @ 0\mod_1188996635000 _79.docx @ 3555 @ 3 @ 1
6.6.4. Table view
The readings are listed in table form in this view.
In the Start | View menu, the Table command is activated. Now
you have to select the data record that you wish to display.
