6 Using the product
167
Designation Explanation
Connection
Output signal of the transmitter.
Display
Display range of the physical unit.
Unit
Specified or user-specific unit.
Voltage output Selection option of whether the power is
to be supplied to the transmitter via the
analog coupler (on) or separately (off).
[Reset sum
channel]
Button for resetting the sum channel. The
sum channel is reset to 0.00.
Pos: 191 /TD/Produ kt verwenden/testo Sa veris/09 Einstellu ngen System/08 Cockpi t Units @ 8\mod_129554086704 4_79.docx @ 75946 @ 3 @ 1
6.10.6. Saveris cockpit unit
Via this menu option, you can configure the measured value
printout using the Testo standard printer.
The measured value printout covers up to the past 12
hours.
The measured value printout includes:
• Print time with date and time
• Tour start/tour stop (date and time)
• Start print area (date and time)
• Name of the tour description and the selected mobile zones
• Probe designation with serial number
