6 Using the product
112
6.2.2. Edit
Pos: 129 /TD/Produ kt verwenden/testo Sa veris/02 Menüs und Befeh le der Ribbon-Leiste/02 B earbeiten/PRO/02 Be arbeiten (Diagr amm)_Pro @ 0\mod_1193998566609_ 79.docx @ 5673 @ 5 @ 1
Editing in the diagram view
The Edit menu (diagram) is only displayed if the diagram has been
activated by clicking into the window.
Menu Edit | Tools (diagram)
Menu
function
Description
Zoom in Drag to form a rectangle in the diagram window
to zoom in on the highlighted area. This
function can also be used during a
measurement in online mode. In the process,
however, the extract shown always displays the
current value.
When you click on [Original size], the diagram
is once again displayed in its overall size.
Crosshairs Crosshairs with which the curve can be
followed are shown by clicking on a point of the
measurement curve. The date, time, measured
value number and measured value are shown
in the process.
Regression
curve
Regression curves are an aid to enable you to
better assess large, unclear amounts of data. In
this process, "outliers" are suppressed and the
actual course of the curve is reproduced using
a theoretical, mathematical function.
The regression curve is shown by clicking on a
measurement curve. The regression
coefficients are shown in the status bar.
Limit values Activate the checkbox to show the limit values
in the diagram.
Menu Edit | Font
Menu function Description
Font
Opens the selection list of available fonts.
Font size
Opens the selection list of available font sizes.
