TESTO Saveris User Manual

7 Maintaining the product
195
Pos: 213 /TD/Übersc hriften/3.2 Techni sche Daten @ 0\mod_1176211 088437_79.doc x @ 704 @ 2 @ 1
7.10. Technical data
Pos: 214 /TD/Leis tungsbeschreibung/ Technische Daten/ testo Saveris/01 Basiss tation Transport @ 9\ mod_1310130675210_79. docx @ 81756 @ 3 @ 1
7.10.1. Saveris base
Characteristic Values
Memory
40,000 values per channel (total max.
18,000,000 values)
Dimensions 225 x 150 x 49 mm
Weight approx. 1510 g
Protection class IP42
Housing material Die-cast zinc/plastic
Radio frequency 868 MHz/2.4 GHz
Power supply
6.3 V DC mains unit; alternatively via 24
V AC/DC plug-in/screw terminals, power
consumption < 4 W.
Rech. batt.
6
Li-ion battery
The rechargeable battery is used only for
backing up data and for emergency SMS
in the event of failure of the power supply,
not for the power supply during operation.
Operating
temperature
+5 ... +45°C
Storage
temperature
-25 ... +60°C
Display graphical LCD display, 4 controls
Interfaces USB, radio, Ethernet
Number of radio
probes
Max. 15 probes can be connected directly
via radio interface,
max. 150 total via
radio/router/converter/extender and
Ethernet, max. 450 channels.
Alarm relay
max. 1 A, max. 30 W, max. 60/25 V
DC/AC, NC or NO contact
GSM module 850/900/1800/1900 MHz
6
Wearing part

TESTO Saveris Specifications

General

Humidity Range	0 to 100 %RH
Measurement Parameters	Temperature, Humidity
Data Transmission	Wireless
Alarm Function	Yes
Resolution	0.1 °C, 0.1 %RH
Radio Frequency	868 MHz, 915 MHz
Data Storage	Internal memory, Cloud
Power Supply	Battery
