TROUBLESHOOTING
POWER TRIM/TILT QUICK REFERENCE CHART
Symptom Pressure check
Check point
Check/repair method
Does not
tilt up
Does not
tilt down
Does not hold Lower chamber
hydraulic
pressure lower
than spec or
pressure drops.
Upper chamber
hydraulic
pressure lower
than spec or
pressure drops.
Lowers Extends
[1] Motor Check according to the motor
check procedure.
[2] manual
valve
Check that the manual valve is
installed securely. Replace if it is
damaged. Check the O-ring for
damage and replace if
necessary. If there is no damage,
clean the O-ring and install it on
the manual valve properly.
[3] Backup ring
O-ring
Check the O-ring for damage and
replace if necessary. If there is no
damage, clean the O-ring and
reinstall it properly.
[4] Backup ring
O-ring
[5] Check valve Check the ball seat for damage or
foreign material. The check valve
cannot be replaced as an
individual part. Replace the free
piston assembly if the check
valve is defective.
[6] O-ring Check the O-ring for damage and
replace if necessary. If there is no
damage, clean the O-ring and
reinstall it properly.
[7] Shock relief
valve
Check the ball seat for damage or
foreign material. The shock valve
cannot be replaced as an
individual part. Replace the
piston rod assembly if the shock
valve is defective.
[8] Dust seal/O-
ring
Check the dust seal and O-ring
for damage. The dust seal and O-
ring cannot be replaced as
individual parts. Replace the
piston rod assembly if the dust
seal or O-ring are defective.
[9] Oil Check the oil level and add the oil
if necessary.
[10] Pump Do not disassemble the pump
assembly. If any of the following
parts are defective, replace the
pump assembly.
[11] Down relief
valve
[12] Lower
chamber check
valve
[13] Lower
chamber spool
valve
[14] Upper
chamber check
valve
[15] Upper
chamber spool
valve
To Next Page
