TOHATSU BFT75A - Page 236

5-95
dummyheaddummyhead
FUEL SYSTEM
Install a new O-ring [1] on the pump case.
Connect the Blue/Yellow wire [2] and Black wire [3]
from the pump harness to the fuel pump.
• Connect the Blue/Yellow wire terminal to the positive
(+) terminal [4] of the pump, and the Black wire
terminal to the negative (-) terminal [5] of the pump
securely.
Tighten the three screw-washers to the specified
torque.
[2]
[1]
[3]
[5]
[4]
TORQUE: 3.4 N·m (0.35 kgf·m, 2.5 lbf·ft)
[1]
