SERVICE INFORMATION
GEAR CASE
EXTENSION/MOUNT CASE
Flywheel bolt M12 x 1.0 103 10.5 76 Apply engine oil to the
threads and seating
surface.
Alternator rotor bolt M14 x 1.5 – – – See page 7-9
Starter motor bolt M10 x 1.25 44 4.5 32
EOP sensor M10 x 1.25 22 2.2 16
EBT sensor/ECT sensor M10 x 1.25 12 1.2 9 Apply sealant to the
threads and seating
surface.
HO2S M18 x 1.5 42 4.3 31
Knock sensor
(BF90D/BF100A only)
M12 x 1.25 31 3.2 23
ECM mounting bolt M6 x 1.0 5 0.51 3.7
Air flow band bolt M5 x 0.8 – – – See page 5-68
Oil case bolt M8 x 1.25 21.5 2.2 16
Water tube joint PT 1/8 9 0.92 6.6 Apply sealant to the
threads and seating
surface.
Fuel pump service check bolt M6 x 1.0 11.8 1.2 9
Pressure regulator bolt M6 x 1.0 11.8 1.2 9
Fuel pump case bolt M6 x 1.0 11.8 1.2 9
Fuel pump cover screw M5 screw 3.4 0.35 2.5
Vapor separator cover
screw/washer
M5 screw 3.40.352.5
Fuel pump strainer cover
screw/washer
M5 screw 3.40.352.5
Fuel pump harness holder mounting
screw
M4 screw 2.10.211.5
Vapor separator water jacket
screw/washer
M4 screw 2.10.211.5
Vapor separator float screw M4 screw 2.1 0.21 1.5
Vapor separator drain screw M6 screw 1.5 0.15 1.1
Fuel injector clip bolt M6 x 1.0 9 0.92 6.6
Water separator body M5 screw 3.4 0.35 2.5
Oil pump sealing bolt M18 x 1.25 39.2 4.0 29
Item
Thread Dia. and pitch Torque values
Remarks
mm (in) N·m kgf·m lbf·ft
Item
Thread Dia. and pitch Torque values
Remarks
mm (in) N·m kgf·m lbf·ft
Gear case bolt
(LRT/LHT/LHG type)
M10 x 1.25 34 3.5 25
Gear case self-lock nut
(XRT type)
M10 x 1.25 34 3.5 25
Pinion gear nut M16 x 1.0 103 10.5 76 Apply gear oil in to the
threads and seating
surface.
Oil check bolt M8 x 1.25 6.5 0.66 4.8
Oil drain plug bolt M8 x 1.25 6.5 0.66 4.8
Impeller housing bolt/washer M8 x 1.25 19.7 2.0 15
Water screen screw M5 x 0.8 1.0 0.10 0.7
Propeller castle nut M18 x 1.5 – – – See page 16-3
Gear case cover B bolt M6 x 1.0 12 1.2 9
64 mm lock nut M64 x 1.5 123 12.5 91 Apply gear oil in to the
threads and seating
surface.
Item
Thread Dia. and pitch Torque values
Remarks
mm (in) N·m kgf·m lbf·ft
Lower rubber mount nut M12 x 1.25 83 8.5 61
Upper rubber mount nut M12 x 1.25 83 8.5 61
