2-6
dummyheaddummyhead
SERVICE INFORMATION
STERN BRACKET
POWER TRIM/TILT (Except LHGX type)
STEERING ROD/REMOTE CONTROL BOX
TILLER HANDLE
Item
Thread Dia. and pitch Torque values
Remarks
mm (in) N·m kgf·m lbf·ft
Stern bracket self lock nut M25 x 2.0 34 3.5 25
Stern bracket self lock nut 7/18-14UNF 34 3.5 25
Grease fitting M6 x 1.0 3 0.31 2.2
Item
Thread Dia. and pitch Torque values
Remarks
mm (in) N·m kgf·m lbf·ft
Cylinder cap – 207.5 21.2 153 Apply marine grease
to the threads.
Rod guide – 139.5 14.2 103 Apply marine grease
to the threads.
Manual valve M14 x 1.5 3.4 0.35 2.5
Socket bolt A and B – 8.3 0.85 6.1
Power tilt motor mounting bolt/
washer
1/4 – 20 UNF 4.9 0.50 3.6
Power tilt motor wire holder screw M4 screw 1.4 0.14 1.0
Oil tank mounting bolt/washer – 4.9 0.50 3.6
Oil tank cap – 2.5 0.25 1.8
Item
Thread Dia. and pitch Torque values
Remarks
mm (in) N·m kgf·m lbf·ft
Steering rod nut 3/8-24 UNF 22 2.2 16
Remote control box cover C screw M5 tapping screw 2.5 0.26 1.8
Fast idle lever screw M5 screw 4.9 0.50 3.6
Power tilt cord clamp screw M5 tapping screw 0.7 0.07 0.5
Emergency stop switch nut M16 x 1.0 1.5 0.15 1.1
Combination switch nut M22 x 1.0 4.9 0.50 3.6
Spring set plate screw M5 tapping screw 2.5 0.26 1.8
Link joint bracket screw M6 x 1.0 5.9 0.60 4.4 Apply locking agent to
the seating surface.
Link joint bracket nut M5 x 0.8 4.9 0.50 3.6
Control wheel bolt M8 x 1.25 23.5 2.4 17
Neutral switch spacer screw M5 tapping screw 2.5 0.26 1.8
Neutral lock block screw M6 tapping screw 2.5 0.26 1.8
Lever setting plate screw M5 x 0.8 4.9 0.50 3.6
Remote control lever grip screw M5 tapping screw 2.5 0.26 1.8
Item
Thread Dia. and pitch Torque values
Remarks
mm (in) N·m kgf·m lbf·ft
Steering bracket bolt M12 x 1.25 29 3.0 21
Under cover screw M5 screw 2.4 0.24 1.8
Cable/clamp bracket bolt M6 x 1.0 7 0.71 5.2 Apply locking agent to
the seating surface.
Connector bracket bolt M6 x 1.0 7 0.71 5.2
Combination switch nut M22 x 1.0 3.9 0.40 2.9
Emergency stop switch nut M16 x 1.0 1.2 0.12 0.9
Grip pipe bolt M6 x 1.0 7 0.71 5.2
Throttle cable pivot nut M5 x 1.0 1.3 0.13 1.0
Switch holder bolt M5 x 1.0 4.5 0.46 3.3
Guide plate bolt M5 x 1.0 4.5 0.46 3.3
Shift frame bolt/washer M6 x 1.0 7 0.71 5.2
