TOHATSU BFT75A - Page 260

6-11
dummyheaddummyhead
ENGINE COVER
Connect the power trim/tilt switch 3P connector [1].
Tighten the flush plug cap [1] against the water joint cap
[2] of the R. engine under cover.
Install the following:
– Front separate cover (page 6-4)
– Engine cover
ENGINE SIDE STOPPER REMOVAL/INSTALLATION
REMOVAL
Remove the L./R. engine under cover (page 6-5).
Release air vent tube C from fuel tube clamp B [1].
Release the fuel hose from the fuel tube clamp B [2].
Remove the bolt/washer [3] and engine side stopper
[4].
Remove the seat side rubber [5], grommet [6], and
collar [7] from the engine side stopper.
[1]
[2]
[1]
[1]
[2]
[4]
[6]
[3]
[5]
[7]
[4]
[3]
[7]
[6]
[5]
