ENGINE COVER
Remove the bolt/washers [1] and pull the under cover
front bracket [2] toward you.
Disconnect the trim angle sensor 3P connector [1] and
the power tilt motor 2P connector [2].
Remove under case grommet C [1] from the under
cover front bracket [2].
Pull out the wires [3] from the hole in the under cover
front bracket.
Remove the under cover front bracket [1] from the
outboard motor.
[2]
[1]
[2]
[1]
[2]
[1]
[3]
[1]
