TOHATSU BFT75A - Page 265

6-16
dummyheaddummyhead
ENGINE COVER
Remove the two bolts [1], two washers [2], and two distance collars [3].
Remove the under cover rear bracket [4] from the outboard motor.
INSTALLATION
Install the under cover rear bracket [1] and two distance collars [2] on the outboard motor.
Install the two bolts [3] and two washers [4] and tighten the bolts.
Connect the water check tube [1] to the under cover
rear bracket [2].
Install the water check tube into the clamp [3] of the idle
exhaust port (page 2-43).
[1]
[2]
[3]
[4]
[3]
[4]
[2]
[1]
[2]
[1]
[3]
