6-15
dummyheaddummyhead
ENGINE COVER
Install the bolt/washer (6 x 95 mm) [1], bolt/washers (6 x
27 mm) [2], and tighten them.
Install the vinyl tube [1] into the under cover front
bracket [2].
Install the following:
– Remote control cable grommet (page 19-5)
– L./R. engine under cover (page 6-7)
– Front separate cover (page 6-4)
– Engine cover
UNDER COVER REAR BRACKET REMOVAL/INSTALLATION
REMOVAL
Remove the following:
– Engine cover
– Front separate cover (page 6-4)
– L./R. engine under cover (page 6-5)
Disconnect the idle exhaust port [1] from the mount
case [2].
Disconnect the water check tube [1] from the under
cover rear bracket [2].
[2]
[1]
[1]
[2]
[2]
[1]
[2]
[1]
