11-7
dummyheaddummyhead
COOLING SYSTEM
Remove the impeller cover [1] and the impeller gasket
[2].
Remove the water pump housing [1] and water pump
gasket [2].
Remove the water pump housing O-ring [3] and two
dowel pins [4].
Remove the gear case grommet [5] and rubber setting
plate [6] from the gear case.
Remove the two water seals [1] using a commercially
available oil seal remover.
[1]
[2]
[4]
[1]
[3]
[2]
[5]
[6]
[1]
