TOHATSU BFT75A - Page 356

13-9
dummyheaddummyhead
ENGINE REMOVAL/INSTALLATION
Tighten each bolt and nut to the specified torque in the
numbered order in two or three steps.
• Do not confuse the bolts on installation.
Connect the oil tube [1] to the mount case [2].
TORQUE: 27 N·m (2.8 kgf·m, 20 lbf·ft)
Tightening
point
Part name Qty
1 – 3 8 X 100 mm bolt (white) 3
4 – 7 8 X 100 mm bolt (black) 4
8 – 10 8 X 120 mm bolt 3
11 – 14 8 X 45 mm bolt 4
15, 19 8 X 45 mm bolt 2
16, 18 8 mm cap nut 2
17 8 X 35 mm bolt 1
1.
5.
8.
4.
12.
11.
13.
9.
3.
2.
7.
10.
6.
14.
15.
16.
17.
18.
19.
[1]
[2]
