ENGINE REMOVAL/INSTALLATION
Loosen the bolt (10 X 35 mm) [1] and install the bolt (10
X 75 mm) [2].
Tighten the bolt (10 X 35 mm) and the bolt (10 X 75
mm) to the specified torque.
Install the regulator/rectifier and fuse box bracket (page
10-4).
Set the vapor separator on the outboard motor, and
connect the fuel pump 2P connector [1].
Set the fuel pump cord [2] in the cord clamper [3].
Install the three bolts [1] to the vapor separator [2] and
tighten them.
TORQUE: 44 N·m (4.5 kgf·m, 33 lbf·ft)
[1]
[2]
[3]
[3]
[2]
[1]
[2]
[1]
[1]
