16-12
dummyheaddummyhead
GEAR CASE
While pushing the lead wire [1] against the projection [2]
on the lower mount center housing as shown, tighten
the screw [3].
Clean the extension case /oil case mating surfaces [1]
thoroughly using a shop towel and degreasing cleaning
solvent.
Apply sealant (ThreeBond
®
#5222L or equivalent) to the
entire sealing surface on the oil case side of the
extension case.
[1]
[2]
[3]
[1]
[3]
[2]
[1]
10 – 15 mm
(0.4 – 0.6 in)
(ThreeBond
®
#5222L
or equivalent)
Application area
