2-27
dummyheaddummyhead
SERVICE INFORMATION
CKP SENSOR 3P
CONNECTOR
IAT SENSOR 2P
CONNECTOR
HARNESS
BAND CLIPS
CKP SENSOR
KNOCK SENSOR
(BF90D/BF100A only)
IAC VALVE 2P
CONNECTOR
IAC VALVE
HARNESS
BAND
CLIPS
MAIN HARNESS
HARNESS
BAND CLIPS
HARNESS
BAND
CLIPS
KNOCK SENSOR 1P
CONNECTOR
(BF90D/BF100A only)
