2-54
dummyheaddummyhead
SERVICE INFORMATION
• Connect by aligning the lugs of the oil tube
and cylinder head cover.
• Install tube clamp D29.0 with the clamp
ends facing down.
OIL TUBE
LUG
LUG
CLAMP ENDS
Set into the clamp of
the mount case.
WATER TUBE B
FUEL HOSE
CLAMP
CYLINDER
HEAD COVER
WATER TUBE A
TUBE CLIP 65
TUBE CLAMP
D29.0
AIR VENT TUBE C
FUEL TUBE CLAMP B
FUEL TUBE C
TUBE
CLIP B10
CYLINDER
HEAD COVER
TUBE CLAMP
D29.0
OIL TUBE
