17
COMPONENTS
(10) Fixed Target Brightness
The patient fixation target brightness can be selected. (see page
50)
(11) REF button, KRT button
If the measurement course by examination purpose is not used,
REF and KERATO continuous measurement (both REF and
KERATO buttons are lit), REF individual measurement (REF but
-
ton only is lit) and KERATO individual measurement (KERATO
button only is lit) can be set arbitrarily. (see page
49)
: REF/KRT continuous measurement
Analysis of refractive wavefront aberration and corneal
wavefront aberration can be done using the obtained
results.
: REF measurement
Analysis of refractive wavefront aberration can be done
using the obtained results.
: KRT measurement
Analysis of corneal wavefront aberration can be done
using the obtained results.
(12) SETTINGS button Various settings are available, for measuring operation, output of
measurement value data and result display format etc. (see page
111)
(13) Exam purpose shortcut button
A shortcut button to select the measurement course according to
the examination purpose.
DETAILS OF FUNCTION BUTTONS
(1) button
Moves to the examination purpose selection screen. (see page 14)
(2) button
Clears all measurement data.
(3) button
The display goes to the ANALYSIS RESULT screen. (See page 77)
(4) button
Transfers the measurement data.
(5) button
Prints the measurement results out via the built-in printer.
(1) Selection of examination button (3) ANALYZE button (5) PRINT button
(2) ALL CLEAR button (4) DATA OUT button
Selection of examination
ALL CLEAR
ANALYZE
DATA OUT
PRINT
