Topcon KR-1W - Setting of Internal Printer (Print Int)

159
FUNCTION SETTING USING SETTINGS
SETTING OF INTERNAL PRINTER (PRINT INT)
PRINT INT menu contains settings related to output from the internal printer.
1 Tap the index "PRINT INT" of the "SETTTINGS screen." Set items of "PRINT INT" are dis-
played.
2 Tap the and/or , as needed, until the set item
to be checked/changed is displayed.
PRINTING THE BARCODE (BARCODE PRINT)
The barcode can be displayed on the printout. The patient ID, machine No. and work ID are
outputted. Before shipment, the default setting is "OFF" (Do not print barcode).
1 Tap the of the set item display "Barcode Print" of "PRINT INT."
2 Tap the and select "ON" (Print barcode) or "OFF" (Do not print
barcode).
3 Setting is complete.
To quit the screen:
• Tap the .
• The "SETTTINGS screen" is quitted and the "MEASUREMENT screen" is
returned.
EXIT button
Page Feed button
Page Return button
Set Condition button
Setting Change butto
n
