88
OPTIONAL OPERATIONS
TO MEASURE ONLY THE RIGHT EYE
The operation procedure is the same as when measuring only the left eye.
INPUT USING USB
This instrument can input ID numbers from a barcode reader, etc. via the USB.
1 Check the connection of USB IN.
For connection, refer to “CONNECTING EXTERNAL I/O TERMINALS” on page 32.
2 Input the patient ID on the measurement and Patient ID input screens from an external device.
The inputted patient ID is displayed on the screen.
OUTPUT USING LAN
This instrument can output data to a PC, etc. via the LAN interface.
1 Connect the network cable to LAN OUT.
For connection, refer to “CONNECTING EXTERNAL I/O TERMINALS” on page 32.
2 Set up of LAN connection settings.
For details, refer to “LAN connection” on page 104.
3 Perform measurements.
4 Tap the button of the control panel.
Output is completed.
NOTE
When the lock icon is displayed (one-eye measurement mode), you can
switch between the left and right eyes while keeping the locked state by
tapping the
button or button.
NOTE
• For explanation of messages during communication refer to the “MES-
SAGE LIST” on page 120.
• All measured data is outputted. If outputting of only individual measure-
ment data (REF measurement data, KRT measurement data or TONO
measurement data only) is required, change the measurement mode to
the individual measurement for desired measurement data by tapping the
button. Then perform measurement and output.
R L
Print out
Measurement mode
