Toro Workman HDX Auto - Brake Caliper Service

Workman HDX AutoPage 5 − 14Chassis
Brake Caliper Service
1. Bolt (2)
2. Caliper body
3. O−ring (4)
4. Caliper bracket
5. Square seal (2)
6. Dust seal (2)
7. Piston (2)
8. Brake pad (2)
9. Caliper anvil
Figure 8
2
3
6
8
1
5
7
4
(37 to 44 N−m)
27 to 33 ft−lb
BAF−12
Assembly
Lube
White
Lithium
Grease
9
