Toro Workman HDX Auto - Primary Clutch Service

Workman HDX AutoPage 4 − 28Drive Train
Primary Clutch Service
1. Spider assembly
2. Shoulder screw (3)
3. Lock nut (3)
4. Clutch weight (3)
5. Moveable sheave
6. Cap
7. Thrust washer (2)
8. Bearing
9. Stationary sheave
Figure 31
2
3
6
8
9
1
5
7
4
40 to 50 in−lb
(4.6 to 5.6 N−m)
