Toro Workman HDX Auto - Front Differential Driveshaft

Workman HDX AutoPage 8 − 8Four Wheel Drive (Optional Kit)
Front Differential Driveshaft
1. Transmission
2. Cap screw
3. Lock nut
4. Front differential driveshaft
5. Front differential assembly
6. CV axle assembly (2)
7. Flange head screw (4)
8. Mount (4)
9. Differential plate (2)
Figure 4
FRONT
RIGHT
1
2
3
4
5
Antiseize
Lubricant
6
6
7
8
9
9
Antiseize
Lubricant
