Toro Workman HDX Auto - Exhaust System

Workman HDX Auto
Page 3 − 14
Kohler Gasoline Engine
Exhaust System
2
3
6
8
9
1
5
7
4
3
4
6
10
11
Figure 16
1. Engine
2. Muffler
3. Carriage screw (4)
4. Flange nut (4)
5. Muffler bracket
6. Clamp assembly (2)
7. Intermediate exhaust pipe
8. Exhaust manifold
9. Flange nut (4)
10. Exhaust gasket (2)
11. Oxygen sensor
FRONT
RIGHT
28 to 36 ft−lb
(38 to 48 N−m)
Antiseize
Lubricant
