Toro Workman HDX Auto - Brake Master Cylinder

Workman HDX AutoPage 5 − 18Chassis
Brake Master Cylinder
1. Brake master cylinder
2. Flange head screw (2)
3. Clevis pin
4. Grease fitting
5. Brake pedal
6. Flange bushing
7. Flange nut
8. Flange nut (2)
9. Cotter pin
10. Shoulder screw
11. Brake shaft
Figure 10
FRONT
RIGHT
1
5
6
4
3
7
10
11
9
8
2
6
