Workman HDX AutoPage 7 − 54Hydraulic System
Lift Cylinder
1. Bed frame
2. O−ring
3. 90
o
hydraulic fitting
4. O−ring
5. Hydraulic hose
6. Lift cylinder (LH shown)
7. Hydraulic hose
8. Cotter pin
9. Frame engine support
10. Frame rail (LH shown)
11. Clevis pin
12. Lynch pin
Figure 44
1
2
3
4
5
6
7
8
9
2
3
4
10
11
12
FRONT
RIGHT
