Toro Workman HDX Auto - Air Cleaner System

Workman HDX Auto
Page 3 − 6
Kohler Gasoline Engine
Air Cleaner System
Figure 6
1. Engine
2. Hose clamp (2)
3. Intake hose
4. Air cleaner assembly
5. Air inlet hood
6. Mounting bracket
7. Flange head screw (2)
8. Flange nut (2)
FRONT
RIGHT
2
3
6
1
5
7
4
2
8
VACUATOR
DIRECTION
