Toro Workman HDX Auto - Chapter 5 - Chassis

Workman HDX Auto Page 5 - 1 Chassis
Chapter 5
Chassis
Table of Contents
SPECIFICATIONS 2............................
GENERAL INFORMATION 3.....................
Operator ’s Manual 3..........................
Tire Pressure 3...............................
SPECIAL TOOLS 4.............................
TROUBLESHOOTING 5.........................
Suspension and Steering 5....................
Brakes 6.....................................
ADJUSTMENTS 8..............................
Parking Brake Adjustment 8....................
Front Wheel Alignment 9......................
SERVICE AND REPAIRS 10.....................
Wheel Assembly 10...........................
Brake System 12.............................
Brake Caliper Service 14......................
Bleed Brake System 16........................
Brake Master Cylinder 18......................
Brake Master Cylinder Service 20...............
Parking Brake Cable 22.......................
Parking Brake Caliper 24......................
Wheel Hub 26................................
Steering Assembly 28.........................
Front Control Arms 32.........................
Front Compression Spring Service 34...........
Front Shock Absorber 36......................
Rear Shock Absorber 37.......................
Rear Leaf Spring 38...........................
Steering Wheel 40............................
Seat Base 42.................................
Hood 44.....................................
Windshield Wiper Assembly (Machines with
Operator Cab) 45...........................
Chassis
