Toro Workman HDX Auto - Speed Limiter Cover Service

Workman HDX AutoPage 4 − 20Drive Train
Speed Limiter Cover Service
1. Speed control hose
2. Button head screw (3)
3. Retainer
4. Banjo washer
5. Rotary union
6. O−ring (2)
7. Speed limiter control cover
8. U−cup
9. Quad ring
10. Hydraulic piston
11. Sleeve bushing
Figure 24
1
2
4
5
3
6
7
8
9
10
11
