Suction
Control
Valve
6.
Remove
the
left
end
of
the
suction
pump
chamber
by
removing
four
screws
(M4
Phillips)
and
four
lock
washers
(M4).
Refer
to
Figure
11-12.
7.
Remove
the
right
end
of
the
suction
pump
chamber
by
removing
four
screws
(M4
Phillips)
and
four
lock
washers
(M4).
Refer
to
Figure
11-12.
8.
Remove
the
suction
pump
enclosure.
Refer
to
Figure
11-13.
Note:
The
suction
pump
enclosure,
an
L-shaped
part,
attaches
to
a
baffle
suction
pump
enclosure.
Do
not
disassemble
the
two
parts.
a.
Remove
four
screws
(M4
Phillips)
and
four
lock
washers
(M4)}—
two
of
each
on
either
end
of
the
enclosure.
b.
Slightly
lean
the
enclosure
toward
the
rear
of
the
console
so
that,
as
you
remove
it,
the
enclosure
will
clear
other
components
in
the
console.
t.
Carefully
pull
the
suction
pump
enclosure
out
the
left
side
of
the
console.
11-22
CUSA
EXcel-8
System
Service
Manual
