ED
Handpiece
Flow
Sensor
Install the
Handpiece
Flow
Sensor
1.
Apply
isopropyl
alcohol
to
the
inside
surface
of
the
3.175
mm
(18
in.)
tube
and
the
outside
surface
of
the
3.175
mm
(18
in.},
90°
elbow
tube
fitting
on
the
bottom
of
the
flow
sensor.
2.
Push
the
3.175
mm
(14
in.)
ID
tube
onto
the
90°
elbow
fitting
on
the
bottom
of
the
flow
sensor.
Make
sure
to
push
the
tube
completely
onto
the
fitting.
3.
Secure
the
tubing
with
a
plastic
wire
tie.
4.
Lower
the
flow
sensor
into
place
and
attach
it
to
the
frame
using
two
screws
(M4
Phillips).
5.
Apply
isopropyl
alcohol
to
the
inside
surface
of
the
1.587
mm
(1/16
in.)
tube
and
the
outside
surface
of
the
1.587
mm
(1/16
in.)
tube
fitting
on
the
top
end
of
the
flow
sensor.
6.
Push
the
1.587
mm
(1/16
in.)
ID
tube
onto
the
tube
fitting
on
the
top
end
of
the
flow
sensor.
Make
sure
to
push
the
tube
completely
onto
the
fitting.
Make
sure,
also,
that the
tube
is
straight
on
the
fitting.
7.
Connect
the
handpiece
cooling
water
sensor
wiring
harness
to
the
ultrasonics
board
at
J5.
8.
Secure
the
handpiece
cooling
water
sensor
wiring
harness
inside
the
cable
restraint
located
above
the
sensor.
The
cable
restraint
will
contain
two
water
tubes
and
the
wiring
harness.
9.
Replace
the
right
side
cover
and
the
rear
cover.
10.
Plug
the
power
cord
connector
into
the
wall
receptacle.
11.
Turn
on
the
AC
Main
Switch,
located
on
the
rear
panel.
11-48
CUSA
EXcel-8
System
Service
Man
