Inputs and Outputs Diagnostics Section
©Vertical Express 3-24 Printed in USA April 2020
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
DZ1 Door Zone #1
EE Electric Eye
EER Electric Eye - Rear
EES Electric Eye Shutoff Switch
EESR Electric Eye Shutoff Switch - Rear
EL1-EL16 Car # Emergency Power Lowering Jewel
EMDIS Emergency Dispatch Operation (Sabbath Operation)
EPA Emergency Power - Automatic
EPAI Emergency Power - Acknowledge Indicator
EPALI Emergency Power - At Designated Landing Indicator
EPCS1-16 Emergency Power - Manual Car Select - Car #n
EPCSI Emergency Power - Car Selected Indicator
EPEPI Emergency Power - Emergency Power Indicator
EPJ Emergency Power - Emergency Power Indicator
EPLDI Emergency Power - Emergency Power Car At Landing Indicator
EPLI Emergency Power Lowering Indicator
EPNP Emergency Power - Normal Power
EPNPI Emergency Power Normal Power Indicator
EPW Emergency Power Warning
ES1-ES16 Car # Emergency Power Selection Jewel
EZNI Express Zone Indicator
F1-F64 Freight SAPB Call - Combination I/O
FALI Failure Indicator
FALNI Not Failed Indicator
FDL1-FDL9 Freight Door Landing Signal
FDR Freight Door Reset - Front
FHS Flashing Hall Signs
FI1-FI64 Freight SAPB Call - Input
FL1-FL64 Hall Call - Floor Lockout
FLO1-FLO64 Hall Call - Floor Lockout Override
FLOR1-FLOR64 Hall Call - Rear - Floor Lockout Override
FLR1-FLR64 Hall Call - Rear - Floor Lockout
FO1-FO64 Freight SAPB Call - Output
FPT Floor Passing Tone
FPTON Floor Passing Tone On
FR1-FR64 Freight SAPB Call - Rear - Combination I/O
FRC Freight Retiring Cam - Front
FRI1-FRI64 Freight SAPB Call - Rear - Input
FRO1-FRO64 Freight SAPB Call - Rear - Output
FRODO Freight Door Open - Front
FRODOR Freight Door Open - Rear
FS1A Fire Service Phase 1 Active (Front)
FS1AI Fire Service - Phase 1 Indicator
FS1FI Fire Service Phase 1 Switch Off Indicator
FS1I Fire Service - Phase 1 Indicator
FS1R Fire Service Phase 1 Recall Active (Front)
FS1RR Fire Service Phase 1 Recall Active (Rear)
FS2A Fire Service Phase 2 Active (Front)
Designator (cont.)
Name
