DIAGNOSTICS
Vertical Express Product Manual 3-25 88500 v.1.0
Diagnostics Section Inputs and Outputs
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
FS2F Fire Service Phase 2 Switch Off (Front)
FS2H Fire Service Phase 2 Switch Hold (Front)
FS2HR Fire Service Phase 2 Switch Hold (Rear)
FS2HX Fire Service Phase 2 Switch Hold (Front) (Rev Logic)
FS2HXR Fire Service Phase 2 Switch Hold (Rear) (Rev Logic)
FS2I Fire Service - Phase 2 Indicator
FSA Fire Service Active (Front)
FSAFI Fire Service - Alternate Floor Indicator
FSAL Fire Service at Designated Landing (Front)
FSBZ Fire Service Buzzer
FSC1 Fire Service - Car - On
FSC2 Fire Service - Car - Off
FSCC Fire Service - Call Cancel
FSDFI Fire Service - Door Failed Indicator
FSDO Fire Service - Fireman's Door Open
FSE Fire Service Sensor - Equipment
FSH1 Fire Service - Hall - Main - On
FSH1A Fire Service - Hall - Main - On
FSH2 Fire Service - Hall - Main - Off
FSH2A Fire Service - Hall - Main - Off
FSH3 Fire Service - Hall - Aux - On
FSH3A Fire Service - Hall - Aux - On
FSH4 Fire Service - Hall - Aux - Off
FSH4A Fire Service - Hall - Aux - Off
FSH5 Fire Service - Hall - Main - Reset (Bypass)
FSH5A Fire Service - Hall - Main - Reset (Bypass)
FSHX Fire Service Phase 2 Switch Hold (Front)
FSHXR Fire Service Phase 2 Switch Hold (Rear)
FSI Fire Service Indicator (Phase 1 or 2)
FSM Fire Service Sensor - Main
FSMFI Fire Service - Main Floor Indicator
FSPO Fire Service Panel Open
FSR Fire Service Phase 1 Recall Active
FSRI Fire Service Return Indicator
FSRR Fire Service Rear Door Closing PH1/PH2
FSSR Fire Service Sensor Reset
FST Fire Service Sensor - High Temperature
FSX Fire Service Sensor - Auxiliary
GCL1-GCL64 Car Call Lockout - Group Wide
GCLR1-GCLR64 Car Call Lockout - Rear - Group Wide
HABD Inspection - Hoistway Access - Bottom - Down
HABDM Inspection - Hoistway Access - Bottom - Down - Monitor
HABU Inspection - Hoistway Access - Bottom - Up
HABUM Inspection - Hoistway Access - Bottom - Up - Monitor
HATD Inspection - Hoistway Access - Top - Down
HATDM Inspection - Hoistway Access - Top - Down - Monitor
HATU Inspection - Hoistway Access - Top - Up
HATUM Inspection - Hoistway Access - Top - Up - Monitor
Designator (cont.)
Name
