Inputs and Outputs Diagnostics Section
©Vertical Express 3-26 Printed in USA April 2020
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
HCIE Hall Call Indicator Enable
HCP Hall Call Power Monitor
HDBI Hoistway Door Bypass Indicator
HDBM Hoistway Door Bypass - Monitor
HDBM2 Hoistway Door Bypass - Monitor #2
HDFI Hoistway Door Interlock Front Closed Indicator - Output
HDRI Hoistway Door Interlock Rear Closed Indicator - Output
HDIFI Hoistway Door Interlock Failure Indicator
HDIFRI Hoistway Door Interlock Failure Rear Indicator
HES Hospital Emergency Service
HESI Hospital Emergency Service Active Indicator
HL1-HL64 Hall Lantern - Landing Signal
HLD2-HLD64 Hall Lantern - Down - Front - Per Landing
HLDR2-HLDR64 Hall Lantern - Down - Rear - Per Landing
HLU1-HLU63 Hall Lantern - Up - Front - Per Landing
HLUR1-HLUR63 Hall Lantern - Up - Rear - Per Landing
HM1 Homing #1 - Lobby Park
HM1I Homing #1 Indicator
HM1NI Homing #1 Not Active Indicator
HM2 Homing #2
HM2I Homing #2 Indicator
HM3 Homing #3
HM3I Homing #3 Indicator
HMCLI Homing - Car At Lobby Indicator
HML Homing - Lobby Recall
HMLI Homing - Lobby Recall Operation Active Indicator
HMLNI Homing - Lobby Recall Operation Not Active Indicator
HPID Hall PI Disable
IB Hoistway Door Interlock Bottom
ID2-ID64 Inconspicuous Riser Call - Down - Combination I/O
IDI2-IDI64 Inconspicuous Riser Call - Down - Input
IDO2-IDO64 Inconspicuous Riser Call - Down - Output
IDR2-IDR64 Inconspicuous Riser Call - Down - Rear - Combination I/O
IDRI2-IDRI64 Inconspicuous Riser Call - Down - Rear - Input
IDRO2-IDRO64 Inconspicuous Riser Call - Down - Rear - Output
IF Hoistway Door Interlock Front
INCL Inspection - Pit
INCLM Inspection - Pit - Monitor
INCN Inspection - Controller
INCND Inspection - Controller - Down
INCNM Inspection - Controller - Monitor
INCNU Inspection - Controller - Up
INCTD Inspection - Car Top - Down
INCTE Inspection - Car Top - Enable Monitor
INCTM Inspection - Car Top - Monitor
INCTU Inspection - Car Top - Up
INHAM Inspection - Hoistway Access Monitor
INRB Inspection Run Bug
Designator (cont.)
Name
To Next Page
