DIAGNOSTICS
Vertical Express Product Manual 3-27 88500 v.1.0
Diagnostics Section Inputs and Outputs
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
INRBD Inspection Run Bug Down
INRBU Inspection Run Bug Up
IR Hoistway Door Interlock Rear
IRO Inconspicuous Riser Operation
IROI Inconspicuous Riser Operation Indicator
IRS Inconspicuous Riser Activation Switch (Not Implemented)
ISC Independent Service - Car
ISCI Independent Service - Car - Indicator
ISH Independent Service - Hall
ISHI Independent Service - Hall - Indicator
IT Hoistway Door Interlocks Top - Series connection of all non-hoistway access front door interlocks.
IU1-IU63 Inconspicuous Riser Call - Up - Combination I/O
IUI1-IUI63 Inconspicuous Riser Call - Up - Input
IUL In Use Light
IUO1-IUO63 Inconspicuous Riser Call - Up - Output
IUR1-IUR63 Inconspicuous Riser Call - Up - Rear - Combination I/O
IURI1-IURI63 Inconspicuous Riser Call - Up - Rear - Input
IURO1-IURO63 Inconspicuous Riser Call - Up - Rear - Output
LBYST Lobby Stop If Passing Lobby Stop At Lobby
LVD Level Down
LVU Level Up
LWA Loadweigher - Anti-nuisance
LWB Loadweigher - Bypass
LWBI Loadweigher - Bypass - Indicator
LWD Loadweigher - Dispatch
LWO Loadweigher - Overload
LWOI Loadweigher - Overload - Indicator
MCC1 Motor Contactor Control #1
MCD Motor Contactors De-energized
MCF Motor Contactor Fault
MCM Motor Contactor Output Monitor
MEC Medical Emergency - Car
MEH Medical Emergency - Hall
MEHI Medical Emergency - Hall Indicator
MEI Medical Emergency - Indicator
MTSTRT Motor is Starting - Indicator - Output
MUTS Motor Up To Speed Input from Electronic Motor Starter (EMS), used by controller for MCE & MCD states.
NATLA Neonatal Hold at Landing A
NATLB Neonatal Hold at Landing B
NATLC Neonatal Hold at Landing C
NATLD Neonatal Hold at Landing D
NATLH Neonatal Hold at Any Landing
NATLI Neonatal Operation Indicator
NATX Neonatal Operation Inputs; x = Floor Number (Baby Monitor)
OFLNI Off Line Indicator
OOSI Out of Service Indicator
PI1-PI64 Position Indicator - Light Up - Car or Controller For Car and Hoistway
PIA1-PIA64 Position Indicator.- Light Up - Alternate Landing Hoistway
Designator (cont.)
Name
