ADJUSTMENT
Vertical Express Product Manual 2-9 88500 v.1.0
Adjustment Section Preliminary Adjustment
CAN Node Address Assignment
(continued)
1. Have some paper and pen/pencil ready to record the following data for future
use: Node ID, SmartName, online status, and channel.
2. Access the UIT.
3. Navigate to BLOCK SELECT ADJUSTMENTS, and press ENTER.
4. Navigate to ADJUST MENU COMMANDS START UP, and press ENTER.
5. After DCN displays, press ENTER.
6. CN Node = 0 displays. Press UP or DOWN to select the proper CN Node ID,
and press ENTER.
7. When Ping a Port? displays, press DOWN.
ADJUST MENU
COMMANDS STARTUP
DCN
—
Display Sta
UP: Next DN: Prev
To Next Page
