DIAGNOSTICS
Vertical Express Product Manual 3-5 88500 v.1.0
Diagnostics Section Adjustments
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
D42 — 0–1
Freight Doors Present - Informs the system that the job has freight doors -
Values:
0 = No freight doors
1 = Freight doors
D43 — 0–1
Door Open Device Stuck Detection Disable - This adjustment, when set to 1, disables the
detection for the door open device and the doors will remain open indefinitely.
D47 sec. 0–1
Wittur Keeper Timeout - The controller will disable Close Door after this time, and the doors
will relax and disengage the clutch.
Values:
0 = Disable (standard operation - provide door close while in motion).
1 = Enable
E10 — 0-2
Emergency Power Type.
Values:
0 = None.
1 = 10D-0C (Type 0) hydraulic battery lower and shutdown.
2 = 10D-3/10D-4; pre A17-2008 (Type 3 or 4). Alternate Power.
3 = 10D-0A (Type 1); PowerVator with traction.
4 = 10D-3/10D-4; A17-2008 (Type 3 or 4). Alternate Power.
5 = Not applicable.
6 = 10D-3/10D-4; A17 2016 (Type 3 or 4).
Note: Power cycle is required for changes to take effect.
E11 floor 1–nf
Emergency Power Return Floor (Car) - During an Emergency Power return phase, this
adjustment sets which floor the car will attempt a return to.
E12 F/R 0–1f
Emergency Power Door - For use with selective doors, this adjusts which door will open at
the return floor (when returning to landing).
Values:
0 = Front
1 = Rear
E13 sec. 10–300
Emergency Power Manual Select Time - When in manual select mode, this adjusts the time
delay before the car is actually selected (Type-4 only).
E14 — 0–1
Okay To Hold Doors Open on Emergency Power.
Values:
0 = False
1 = True
E17 floors 1–nfloors
Emergency Power Return Floor (Group) - During an Emergency Power return phase, this
adjustment sets which floor the car will attempt a return to.
E18 cars 1–ncars
Maximum Elevators on Emergency Power - This is the maximum number of cars allowed to
run simultaneously on Emergency Power Operation.
E19 min. 2–10
Emergency Power Extended Lowering Time - Use this adjustment to set the time allowed
for cars to arrive at the emergency power floor.
E20-E34 ncars 0–ncars
Emergency Power Lowering - This adjustment sets the automatic lowering sequence for
Emergency Power Operation.
Note: E20 would be the first elevator to lower, and E34 would be the last elevator to lower.
E35-E49 ncars 0–ncars
Emergency Power Run - This adjustment sets the automatic select to run sequence for
Emergency Power Operation.
Note: E35 would be the first elevator to run, and E49 would be the last elevator to run.
E50 sec. 0–60
Emergency Power Lower Timer - This adjustment sets the time for each group in the lower-
ing sequence.
Note: If the groups are powered up simultaneously, the previous group has sufficient time
to initialize and begin to lower.
E51 sec. 0–100
Emergency Power Auto Select Timer - If the groups are powered up on Emergency Power
simultaneously, this adjustment sets the time for each group in the lowering sequence to
initialize and begin lowering.
