Adjustments Diagnostics Section
©Vertical Express 3-8 Printed in USA April 2020
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
F26 — 0–4
This adjustment will set variations of Smoke Sensor Operation for Standard 2000 Fire Ser-
vice (A17 and B44).
Values:
0 = The Standard 2000 (A17 and B44) fire service sensor operation is active.
1 = The Maryland variation of 2000 fire service is active. Maryland allows the active recall
floor to be changed from the main landing to the alternate landing if the main landing
sensor is active, the secondary switch (if provided) is in the OFF position, and the pri-
mary switch is moved to the RESET position and then to the OFF position.
2 = The Ohio variation of 2000 fire service is active. Ohio allows the alternate landing recall
on Phase 1 to be overridden: place either the primary or secondary switch in the ON
position and the car will move to the main landing. The car will revert to the alternate
landing recall if the primary switch and the secondary switch (if provided) are in the
OFF position and the main landing sensor is still active.
3 = The Massachusetts variation of 2000 fire service is active. Massachusetts allows the
alternate landing recall on Phase 1 to be overridden: place the primary switch in the
ON position and the secondary switch will be ignored if the main landing sensor is
active.
4 = The Manchester, NH variation of 2000 fire service is active. Manchester allows fire ser-
vice initiated by sensors to be deactivated: reset all sensors and no required switch
change is needed.
F31 floors 1-nfloors
Group Fire Recall Landing – This adjustment sets the designated floor position number for
the Main Fire Recall Floor.
Note: This should be set to the floor location of the Phase 1 Fire Service Key Switch.
F32 floor 1–nfloors
Group Alternate Fire Recall Floor - This is the designated floor position number for the
Alternate Fire Landing.
F33 — 0–1
Flash FSRI on FSE Activate First
Inhibit flashing of fire hat if FS PH1 is activated by some means other than machine room
or hoistway smoke sensor.
Values:
0 = Flash FSRI anytime the machine room smoke input is active.
1 = Only flash FSRI if machine room or hoistway smoke sensors are activated before other
FS PH1 activation means.
H11 F/R 0–1
Homing Return Door 1 - This adjustment assigns which door will open at return floor 1
(when the landing has selective doors).
Values:
0 = Front
1 = Rear
H12 floor 1–nf
Homing Return Landing 2 - This adjustment changes the floor the car returns to during car
homing operation. To activate, use Input HM2.
H13 F/R 0–1
Homing Return Door 2 - This adjustment assigns which door will open at return floor 2
(when the landing has selective doors).
Values:
0 = Front
1 = Rear
H14 floor 1–nf
Homing Return Landing 3 - This adjustment changes the floor the car returns to during car
homing operation. To activate, use Input HM3.
H15 F/R 0–1
Homing Return Door 3 - This adjustment assigns which door will open at return floor 3
(when the landing has selective doors).
Values:
0 = Front
1 = Rear
H16 0.1 sec. 0–600
Homing Door Time - This adjustment sets the door time used when at the return landing
(during car homing operation).
Adj (cont.) Unit Range Definition (cont.)
