Setup I-O Matrix - Map Input to Control Relay Setup I-O Matrix - Map Sensor to Control Relay
SETUP I/O MATRIX
Program input & sensors
to control relays
Select to map inputs or sensors
1=MAP INPUT TO CONTROL RELAY
2=MAP SENSOR TO CONTROL RELAY
3=RETURN TO SETUP MENU
4=RETURN TO MAIN MENU
SELECT A NUMBER:1
SETUP I/O MATRIX
Program input & sensors
to control relays
Select to map inputs or sensors
1=MAP INPUT TO CONTROL RELAY
2=MAP SENSOR TO CONTROL RELAY
3=RETURN TO SETUP MENU
4=RETURN TO MAIN MENU
SELECT A NUMBER:1
MAP INPUT TO CONTROL RELAY
Program input
to control relays
Select input to map
INPUTCONTROL RELAY
1 2
1=DEVICE_1N N
2=DEVICE_2N N
3=DEVICE_3N N
4=DEVICE_4N N
5=DEVICE_5N N
6=DEVICE_6N N
7=DEVICE_7N N
8=DEVICE_8N N
0=RETURN TO SETUP I/O MATRIX
I=RETURN TO SETUP MENU
SELECT A NUMBER:1
MAP SENSOR TO CONTROL RELAY
Program sensor
to control relays
Select sensor to map
SENSORCONTROL RELAY
1 2
1=SENSOR_1 HIGH STPTN N
2=SENSOR_1 LOW STPTN N
3=SENSOR_2 HIGH STPTN N
4=SENSOR_2 LOW STPTN N
5=SENSOR_3 HIGH STPTN N
6=SENSOR_3 LOW STPTN N
7=SENSOR_4 HIGH STPTN N
8=SENSOR_4 LOW STPTN N
9=RETURN TO SETUP I/O MATRIX
0=RETURN TO SETUP MENU
SELECT A NUMBER:1
Vertiv | Liebert® AC8 User Manual | 160
