2.2 Surface-Mounting the Liebert AC8
NOTE: Removing the conduit knockouts before mounting the Liebert AC8 on the wall will ease
installation and prevent strain on the mounting hardware and wall. It is imperative to remove the
knockouts if the unit is to be flush-mounted.
After determining where to place the unit, check to ensure that you have all the hardware required to
install the panel on the surface of a wall. Obtain the needed tools and material.
Required tools
• Electric drill (if surface is too hard to drive screws without pilot holes)
• Screwdriver
• Marker to denote layout of holes
• Four screws, each #10
2.2.1 Mounting the Panel
CAUTION: Check building plans and other relevant documents to determine whether mounting
the Liebert AC8 at the selected location might cause cutting or otherwise damaging electrical
or communication wiring or pipes.
To mount the panel:
1. Mark the wall for mounting holes, using the back of the unit as a template (see Figure 2.1 on
the facing page).
2. Drill holes, if required, to install the four #10 screws that will secure the Liebert AC8 to the wall.
Clean up the debris.
3. If the wall material is not strong enough to hold the screws securely, use wall anchors.
4. Install the top two screws—the screw heads must be small enough to slip through the larger,
bottom portion of the pear-shaped mounting slot in the Liebert AC8 (see inset in Figure 2.1 on
the facing page). The screws must also be large enough to extend over the edges of the top of
the mounting slot.
5. Hang the Liebert AC8 on the screws, letting the panel slip down until the screws are in the
smaller, upper portion of the slot.
6. Tighten the screws until they are snug.
7. Insert the remaining two screws in the bottom holes on the back of the panel and tighten.
