4.2 Main Menu Overview
The Main Menu offers access to all functions within the panel. As shown in Table 4.2 below, the functions
are organized into three sections with step-by-step instructions.
Section Description
View Status Options on page35 -
View Status Options (both LCD
and Service Terminal Interface)
These features are available to all users. This permits all personnel to check the status of any monitored
equipment or location. From this menu, any user may:
View current monitoring data—active alarms andthe status of inputs and outputs
View data stored in alarm, event and trend logs
View pager numbers
View auto sequencing and standby testing status
Silence Alarm & BackupLog Files
(Service Terminal Interface) on
page49 - Silence Alarm &
Backup Log Files (Service
Terminal Interface only)
These features—available via the Service Terminal Interface only—allow users to:
Silence the audible alarm
Back up the alarm, event and trend logs
System and Control Options on
page53 - System and Control
Options (some functions available
via Service Terminal Interface
only)
These options require a password. Authorized users may:
Configure the Liebert AC8
Override automatic control of outputs to force an output ON or OFF
Clear active alarms and delete all records in the alarm, event and trend logs
Table 4.2
Primary functions overview
4.3 LCD Menu Overview
Figure 4.1 on the facing page shows an overview of the initial screens available through the LCD
interface. For comparable information about the Service Terminal Interface screens, see Overview of
Menus.
